OPERATION

After connecting the device to the mains it is ready for operation. The display indicates the last operating
mode. The operating modes can be selected by means of the display and the control buttons. All settings
remain stored even if the device is disconnected from the mains. The device can be operated in stand-alone
mode via the control board and the EUROLITE IR-7 remote control or in DMX-controlled mode via any
commercial DMX controller and QuickDMX with suitable wireless transmitter.

Operating buttons

Button
MENU
ENTER
UP
DOWN

Menu structure

Mode
DMX mode
Automatic mode
Running speed in
automatic mode
White color setting
Dimmer
Fade in and out
Strobe effect
Behavior in case of
missing DMX signal
Slave mode
Key lock
Wireless 2.4 G
IR remote control
Firmware version
Function
Selects the operating mode or returns to the initial screen.
Activates a value to be modified or saves a value when modifying.
Selects the next menu item or increases values when modifying.
Selects the previous menu item or decreases values when modifying.
Display
4CH
DMX 2CH
1CH
AUTO
SPEED
COLOR
DIMMING
FADING
FLASH
DMX lost
SLAVE SLAVE MODE
PASSCODE
SET 2.4 G
ON/OFF
INFRARED
Vx.x
ADDR:001-512
4-channel mode and start address
ADDR:001-512
2-channel mode and start address
ADDR:001-512
1-channel mode and start address
01-04 Auto programs 01-04
Program running speed
01-09
slow > fast
W000-255
Warm white 0-100%
Total brightness
01- 99
dark > bright
Fading program
00-99
slow > fast
Strobe effect
00-99
slow > fast
Blackout LEDs switched off
Hold Most recent DMX value is held
Full All LEDs light at 100% brightness
Auto Last selected auto program (01-04)
Slave mode
ON Key lock on
OFF Key lock off
Red
Green
Blue
Transmission channel wireless DMX
R+G
G+B
R+B
ON IR remote control on
OFF IR remote control off
Vx.x Firmware version number
26/32
Function
00138977, Version 1.0
