ENGLISH
1. Pull out the rails.
2. Place the rear part of the drawer (1) on
the rails.
1
3. Keep the front of the drawer (2) lifted up
while pushing the drawer in.
4. Press the front part of the drawer
downwards.
Pull out the drawer again and
check if it is placed correctly on
both rear and front hooks.
Sliding shelf
Top of the vegetable drawer is equipped
with sliding shelf that houses two removable
bins, it can be repositioned according to
individual preference for better accessibility.
Containers are secured with individual lids to
isolate unwanted odours.
2
Removing Extra Zone
To remove the Extra Zone from the fridge
cabinet follow the steps below:
1. Pull out the vegetable drawer from the
refrigerator.
2. Lift the Extra Zone compartment and pull
out the glass cover with humidity control
from underneath it.
3. Hold the drawer together with the glass
cover of the Extra Zone compartment
and pull them towards yourself.
19
