Plumbing; Cold Water Connection; Hot Water Connection; Drain Valve (Dv) - Miele PWM 511 Installationsplan

en - Technical data

Plumbing

Cold water connection

Required flow pressure
Maximum flow rate
Threaded union required (male thread, to be provided by customer in accordance with
DIN 44991, flat sealing)
Length of water inlet hose included in scope of supply

Hot water connection

Maximum permissible hot water temperature
Required flow pressure
Maximum flow rate
Threaded union required (male thread, in accordance with DIN 44991, flat sealing)
Length of water inlet hose supplied

Drain valve (DV)

Maximum waste water temperature
Drain connection (on machine)
Drain (on site)
Maximum drainage rate

Drainage (DP)

Maximum waste water temperature
Drain connection (on machine)
Maximum drainage rate

Equipotential bonding

Connection with male thread
Washers and nuts
If local and national installation specifications require equipotential bonding, good galvanic contact must be guaranteed. Accessories
for equipotential bonding are not supplied and need to be ordered separately.

Installation dimensions

Casing width (without add-on components)
Casing height (without add-on components)
Casing depth (without add-on components)
Overall machine width
Overall machine height
Overall machine depth
Minimum width of transport opening
Minimum safety distance between wall and back of machine
Diameter of door opening
Door opening angle
42
100 - 1000 kPa (1 - 10 bar)
10 l/min
3/4"
1550 mm
70 °C
100 - 1000 kPa (1 - 10 bar)
10 l/min
3/4 "
1550 mm
95 °C
Plastic pipe HT DN 70
Connection DN 70
200 l/min
95 °C
External diameter 22 (DN 22)
26 l/min
10×35 mm
M10
692 mm
1012 mm
818 mm
700 mm
1020 mm
845 mm
800 mm
400 mm
370 mm
180°
