turck FS101 Serie Betriebsanleitung Seite 8

Produktbeschreibung
Geräteübersicht
Ø 38 [1.50]
M12 × 1
M18 × 1.5
Ø 8.5 [0.33]
Ø 7.3 [0.29]
mm [Inch]
Abb. 3: Abmessungen
– Sensor mit Einschraubadapter G3/4"
Ø 38 [1.50]
M12 × 1
M18 × 1.5
Ø 8.5 [0.33]
Ø 7.3 [0.29]
mm [Inch]
Abb. 4: Abmessungen
– Sensor mit Einschraubadapter NPT 1/2"
Ø 38 [1.50]
M12 × 1
M18 × 1.5
Ø 8.5 [0.33]
Ø 7.3 [0.29]
mm [Inch]
Abb. 5: Abmessungen
– Sensor mit Einschraubadapter NPT 3/4"
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
96.4 [3.79]
22
L1
96.4 [3.79]
22
L1
96.4 [3.79]
22
L1
55.1 [2.17]
12.2 [0.48]
M18 × 1.5
32/11
9.5
[0.37]
G 3/4
L
55.1 [2.17]
12.2 [0.48]
M18 × 1.5
27/11
9.5
[0.37]
NPT 1/2
L
55.1 [2.17]
12.2 [0.48]
M18 × 1.5
32/11
9.5
[0.37]
NPT 3/4
L
Ø 8.7 [0.34]
37
[1.46]
14.5 [0.57]
Ø 8.7 [0.34]
37
[1.46]
14.5 [0.57]
Ø 8.7 [0.34]
37
[1.46]
14.5 [0.57]
V01.00 | 2023/05 | 8
