5. TECHNICAL SPECIFICATIONS

EN
HEATING CABLES
Electrical Properties
DE
Supply voltage
FR
Power consumption
NL
Output relay / contactor /
heating cable
DA
Power supply terminals
FI
Heating cables terminals
contactor
NO
Alarm terminals
SE
Sensor terminals
CZ
Alarm relay
LT
Real time clock
PL
Clock back up
RU
Clock accuracy
ZH
Settings
Exposure temperature
IT
Storage temperature
Selectable temperature range
Enclosure
Material
Dimensions
Ingress protection class
Weight
Mounting
Flammability class
Sensor
Temperature
sensor type
Sensor tip
dimensions
Sensor cable
length
Cable extension
Temperature
range
Approval
CE, UKCA
|
10 nVent.com/RAYCHEM
nVent RAYCHEM freeze protection cables
230 VAC –15/+10%; 50/60 Hz
4 VA
2 x 4 A / 230 VAC
3 x 1,5 mm²
2 x 2 x 1,5 mm²
3 x 1,5 mm²
2 x 2 x 1,5 mm²
Single pole double throw relay, voltage–free, rating
2 A/250 VAC
Automatic summer/winter time and leap year
correction
10 days
A variation of +/– 10 min per year is possible
All settings are stored in a non-volatile memory
0°C to +40°C
−20°C to +50°C
0°C to +80°C (when used with SM-PT100-2 up to
+245°C)
PPE (polyphenylene ether)
158 mm x 110 mm x 56 mm
IP20
550 g
DIN-Rail mountable 35 mm
D category (DIN EN60730/VDE0631-1)
Standard
(included in box) HARD-78
NTC 2 kOhm /
25°C, 2-wire
Ø 5 mm, length
20 mm
5 m
Up to 150 m, cross
section extension
cable: 2 x 1,5 mm²
—40°C to +90°C
see page 76
EMC: EN 61000-6-3, EN 61000-6-2
With SM-PT100-2 Module
PT100
Ø 6 mm, length
50 mm
3 m
Up to 150 m,
3 x 1,5 mm²
–40°C to +150°C
MONI-PT100-260/2
PT100
Ø 6 mm, length
50 mm
2 m
Up to 150 m,
3 x 1,5 mm²
–50°C to +260°C
