8.2 4 - 20 mA Ausgangssignalbereich
Gas / Sensor
3MS Trimethylsilan
AsH3 Arsin (3 El.)
AsH3 Arsin (2 El.)
AsH3 Arsin (2 El.)
B2H6 Diboran
Br2 Brom
C4F6 Hexafluorbutadien
C5F8 Octafluorcyclopenten
CH3F Methylfluorid
CH4 Methan
Cl2 Chlor
ClF3 Chlortrifluorid
ClO2 Chlordioxid
CO Kohlenmonoxid
COCl2 Phosgen
DCE 1,2 Dichlorethen 1,2
F2 Fluor
F2 Fluor
GeH4 Germaniumwasserstoff
H2 Wasserstoff (1 %)
H2 Wasserstoff (4 %)
H2S Schwefelwasserstoff
H2S Schwefelwasserstoff (org.)
H2Se Selenwasserstoff
HBr Bromwasserstoff
HCl Chlorwasserstoff
HCl Chlorwasserstoff (tropic)
HCN Cyanwasserstoff
HF Fluorwasserstoff
HMDS Hexamethyldisilazan
HMDS Hexamethyldisilazan
N2H4 Hydrazin
NF3 Stickstofftrifluorid
NH3 Ammoniak (100 ppm)
NH3 Ammoniak (1000 ppm)
NO Stickstoffmonoxid
NO2 Stickstoffdioxid
O2 Sauerstoff
O3 Ozon
O3 Ozon
Satellite XT 4-20 mA Versionen
Artikel-Nr.
Sensor Min
9602-6210 0 ... 7.5
9602-6001 0 ... 0.15
9602-6000 0 ... 0.15
9602-6002 0 ... 3.0
9602-6200 0 ... 0.30
9602-6800 0 ... 0.30
9602-9732 0 ... 30.0
9602-9730 0 ... 6.0
9602-9720 0 ... 0.300
9602-9900 0 ... 60
9602-5300 0 ... 1.50
9602-7410 0 ... 0.30
9602-7400 0 ... 0.30
9602-5400 0 ... 75
9602-6600 0 ... 0.30
9602-9600 0 ... 600
9602-6400 0 ... 0.30
9602-6401 0 ... 9
9602-6900 0 ... 0.6
9602-5100 0 ... 0.300
9602-5101 0 ... 3.00
9602-5200 0 ... 30
9602-5201 0 ... 30.0
9602-5600 0 ... 0.15
9602-7000 0 ... 6.0
9602-5800 0 ... 15.0
9602-5801 0 ... 15.0
9602-5700 0 ... 15.0
9602-6500 0 ... 9.0
9602-6714 0 ... 300
9602-6715 0 ... 0.300
9602-7600 0 ... 0.30
9602-9700 0 ... 30.0
9602-6704 0 ... 60
9602-6705 0 ... 300
9602-7200 0 ... 75
9602-7300 0 ... 9.0
9602-5500 0 ... 25.0
9602-7100 0 ... 0.30
9602-7101 0 ... 0.30
Fortsetzung umseitig
Referenzteil - Kapitel 8
4 - 20 mA Bereich
Standard Max Einheit Wert
20.0 50.0
1.00 10.00
1.00 10.00
10.0 10.0
1.00 10.00
5.00 10.00
50.0 100.0
20.0 50.0
0.500 1.000 Vol.-%
100 100 % UEG
5.00 10.00
1.00 5.00
1.00 5.00
500 1000
1.00 10.00
1000 1000
5.00 10.00
30 50
5.0 10.0
1.000 1.000 Vol.-%
4.00 10.00 Vol.-%
100 500
30.0 50.0
1.00 10.00
30.0 50.0
30.0 50.0
30.0 50.0
30.0 50.0
10.0 50.0
500 1000
0.500 1.000 Vol.-%
1.00 10.00
50.0 100.0
100 200
1000 1000
250 1000
25.0 100.0
25.0 30.0 Vol.-%
1.00 10.00
1.00 10.00
Alarm 1
ppm 2.5
ppm 0.05
ppm 0.05
ppm 1.0
ppm 0.10
ppm 0.10
ppm 6.0
ppm 2.0
0.100
20
ppm 0.50
ppm 0.10
ppm 0.10
ppm 30
ppm 0.10
ppm 200
ppm 0.10
ppm 3
ppm 0.2
0.100
1.00
ppm 10
ppm 10.0
ppm 0.05
ppm 2.0
ppm 5.0
ppm 5.0
ppm 10.0
ppm 3.0
ppm 100
0.100
ppm 0.10
ppm 10.0
ppm 20
ppm 100
ppm 25
ppm 5.0
18.0
ppm 0.10
ppm 0.10
8 - 3
