saw blade, check to see that it spins freely in
the table insert (16) in both perpendicular and
45° angle settings.
•
Warning! You should replace the table insert
(16) immediately whenever it is worn or da-
maged. To do so, undo the Philips screws in
the table insert (16) and take the table insert
out of the fixed saw table (18). To fit the new
table insert (16), proceed in reverse order.
•
Warning! The work to change and align the
saw blade (7) must be carried out correctly.
6.8 Transport (Fig. 1-3)
•
Press down the locking lever (20) to lock the
turntable (19).
•
Using the scale (25), make sure that the
angle for miter cuts is 90°. In addition, the
machine head (4) must be secured with the
locking grip (26).
•
Press the machine head (4) downwards and
secure with the retaining pin (30). The saw is
now locked in its bottom position.
•
Fix the saw's drag function with the locking
screw for drag guide (29) in rear position.
•
Carry the equipment by the fixed saw table
(18).
•
To set up the equipment again, proceed as
described in section 5.3.
6.9 Operating the laser (Fig. 1, 18)
Switching on: Move the On/Off switch (42) to the
" " position to switch on the laser (41). A laser
line is projected onto the material you wish to pro-
cess, providing an exact guide for the cut.
Switching off : Move the On/Off switch (42) to the
"OFF" position.

7. Replacing the power cable

Danger!
If the power cable for this equipment is damaged,
it must be replaced by the manufacturer or its
after-sales service or similarly trained personnel
to avoid danger.
Anl_TE_SM_8_L_Dual_SPK13.indb 31 Anl_TE_SM_8_L_Dual_SPK13.indb 31
GB
8. Cleaning, maintenance and
ordering of spare parts
Danger!
Always pull out the mains power plug before star-
ting any cleaning work.
8.1 Cleaning
•
Keep all safety devices, air vents and the
motor housing free of dirt and dust as far as
possible. Wipe the equipment with a clean
cloth or blow it with compressed air at low
pressure.
•
We recommend that you clean the device
immediately each time you have finished
using it.
•
Clean the equipment regularly with a moist
cloth and some soft soap. Do not use
cleaning agents or solvents; these could at-
tack the plastic parts of the equipment. Ensu-
re that no water can seep into the device. The
ingress of water into an electric tool increases
the risk of an electric shock.

8.2 Carbon brushes

In case of excessive sparking, have the carbon
brushes checked only by a qualifi ed electrician.
Danger! The carbon brushes should not be rep
laced by anyone but a qualifi ed electrician.
8.3 Maintenance
There are no parts inside the equipment which
require additional maintenance.
8.4 Ordering spare parts and accessories
Please provide the following information when
ordering spare parts:
•
Type of unit
•
Article number of the unit
•
ID number of the unit
•
Spare part number of the required spare part
For our latest prices and information please go to
www.Einhell-Service.com
Tip! For good results we
recommend high-quality ac-
cessories from
www.kwb.eu
