Checkpoint
Troubleshooting
1 The sling is placed under
If the sling is placed with folds it risks
user's limb as required with
discomfort and pressure on the user's
no folds.
body part.
2 Do not lift higher than
Lifting the user higher than what the
the user's mobility of the
joints can sustain poses the user to a
joints can sustain.
risk of injury.
3 The lifting straps are
If the straps are stretched unequally,
stretched simultaneously
the sling may be pulled out of position,
when the lift is started. See
and there may be a risk of the user's
'Lifting checkpoints' below.
body part sliding out.
Lifting checkpoints
1
2
1 Check that the sling is correctly fitted around the user's limb and that
the lifting loops are correctly fitted to the sling bar hooks.
2 Start lifting. Ensure that the lifting straps are stretched tense, and
pause before lifting. Check that both lifting loops are attached correctly
to the sling bar before lifting the user.
3 Carry out the planned LimbLift.
Sling application
1 Use the application pocket on the sling for easier fitting.
2 Push the sling under the user so it is possible to pull out on the opposite
side.
3 Pull the sling and center it under user's body part(s).
4 Make sure the lifting straps are fastened with equal length on right
and left side.
1
3
Removing the sling
1
1 Lower the user's
body part. Release the
lifting band from the
sling bar.
2 Remove the sling by
folding the lifting band
under the sling itself
and pull out.
3
2
4
2
The Molift UnoSling LimbLift, as described in this manual, is CE label-
led and complies with the Council of Europe's directive on medical
devices MDR (EU) 2017/745, class 1, and has been tested and appro-
ved in accordance with the EN ISO 10535:2021 standard.
This symbol indicates especially important safety information.
Follow these instructions carefully.
Do not wash. If the sling is washed, this symbol disappears
and another symbol appears. The sling should then be
disposed of.
Do not use. If this symbol appears the sling has been
washed and should be disposed of.
The sling should not be stored in direct sunlight.
Safe Working Load (SWL): 200 kg (440 lbs)
Material: Polypropylene, polyester
2-point
sling bar
Small 340 mm
Medium 440 mm
Large 540 mm
Item no.
Sling model
Molift UnoSling LimbLift
3100020
Single-patient sling, consumer item
Molift UnoSling LimbLift
3100030
Single-patient sling, consumer item
A
Size in mm
Standard
Wide
Visit www.etac.com to download documentation to ensure that you
have the latest version.
Molift UnoSling / www.etac.com
Size of sling
Standard
Wide
p
p
p
p
p
p
Size
Standard
Wide
B
C
A
B
C
380
950
150
380
950
250
5
