Product Features

The numbering of the product features refers to the illustration of the ma-
chine on the graphics page.
1 Tool holder
2 Lighting ring
3 Hexagon collet
4 Switch lever for angular adjustment
5 Battery (PSR 3,6 V)
6 Battery unlocking button (PSR 3,6 V)
7 On/Off switch (Right-hand/left-hand rotation)
8 Light
9 Universal bit holder*
10 Screwdriver bit*
11 Socket for charger plug (PSR 2,4 V)
12 Charger plug
13 Charger cradle (PSR 3,6 V)
* Illustrated or described accessories are not included as standard delivery.

Tool Specifications

Cordless Screwdriver
Article number
Rated voltage
No-load speed
Max. torque for hard/soft
screwdriving application
according to ISO 5393
Screw diameter, max.
Battery Charger
Charging time
Please observe the article number on the type plate of your machine. The trade
names of the individual machines may vary.
19 • 1 609 929 H44 • 21.07.06
PSR 2,4 V
3 603 J38 6..
[V=] 2.4
[rpm] 130
[Nm] 3.2/2.0
[mm] 5
2.4 V/620 mA 3.6 V/600 mA
[h] 5 – 6
English - 5
PSR 3,6 V
3 603 J38 7..
3.6
170
4.5/2.8
6
5 – 6
