Fronius OPT/i SpeedNet Connection iWave230i Installationsanleitung Seite 12

Remove dummy cover
Installing OPT/i
SpeedNet Con-
nection iWa-
ve230i
12
(1)
(1)
1
1
Remove TX25 5x12 mm screws (1)
2
Remove 2 TX20 4x12 mm screws (2)
3
Fold TPC220 PC board on the bottom
4
upward and remove from the PC
board holder
Remove dummy cover (1) from the in-
1
side out
Insert the SpeedNet Connection into
1
the opening from the inside to the out-
side
