1 1
Replace the TPC220 PC board
Connect cable from SpeedNet Con-
10
nection as per cable label on the 4-pin
Molex plug:
X2:4
X2:2
Attach cable using cable tie
11
Cut off cable ties
12
Place the TPC220 PC board in the PC
1
board holder on the upper holders as
shown
15
