12 | English
 Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally oc-
curs, flush with water. If liquid contacts eyes, addition-
ally seek medical help. Liquid ejected from the battery
may cause irritation or burns.
Service
 Have your power tool serviced by a qualified repair per-
son using only identical replacement parts. This will en-
sure that the safety of the power tool is maintained.
Hammer Safety Warnings
 Wear ear protectors. Exposure to noise can cause hear-
ing loss.
 Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory
or fastener may contact hidden wiring. Cutting accesso-
ry and fasteners contacting a "live" wire may make ex-
posed metal parts of the power tool "live" and could give
the operator an electric shock.
 Use appropriate detectors to determine if utility lines
are hidden in the work area or call the local utility com-
pany for assistance. Contact with electric lines can lead
to fire and electric shock. Damaging a gas line can lead to
explosion. Penetrating a water line causes property dam-
age.
 Switch off the power tool immediately when the tool in-
sert jams. Be prepared for high reaction torque that
can cause kickback. The tool insert jams when:
— the power tool is subject to overload or
— it becomes wedged in the workpiece.
 Secure the workpiece. A workpiece clamped with clamp-
ing devices or in a vice is held more secure than by hand.
 Always wait until the machine has come to a complete
stop before placing it down. The tool insert can jam and
lead to loss of control over the power tool.
 Do not open the battery. Danger of short-circuiting.
Protect the battery against heat, e. g., against
continuous intense sunlight, fire, water, and
moisture. Danger of explosion.
 In case of damage and improper use of the battery, va-
pours may be emitted. Ventilate the area and seek
medical help in case of complaints. The vapours can irri-
tate the respiratory system.
 Use the battery only in conjunction with your Bosch
power tool. This measure alone protects the battery
against dangerous overload.
 Use only original Bosch batteries with the voltage list-
ed on the nameplate of your power tool. When using oth-
er batteries, e.g. imitations, reconditioned batteries or
other brands, there is danger of injury as well as property
damage through exploding batteries.
1 609 92A 09P | (28.5.13)
Product Description and Specifica-
tions
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
Intended Use
The machine is intended for hammer drilling in concrete,
brick and stone. It is also suitable for drilling without impact in
wood, metal, ceramic and plastic. Machines with electronic
control and right/left rotation are also suitable for screwdriv-
ing.
The light of this power tool is intended to illuminate the power
tool's direct area of working operation and is not suitable for
household room illumination.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 SDS-Quick tool holder
2 Dust protection cap
3 Locking sleeve
4 Selector switch for drilling/hammer drilling
5 Indicator for right rotation
6 Indicator for left rotation
7 Rotational direction switch
8 On/Off switch
9 Battery charge-control indicator
10 Battery pack*
11 "PowerLight"
12 Universal bit holder*
13 Screwdriver bit*
14 Screwdriver bit with ball catch*
15 Drill bit with hexagon shank*
16 Drill bit with SDS-Quick tool holder*
17 Handle (insulated gripping surface)
18 Battery unlocking button
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Noise/Vibration Information
Measured sound values determined according to EN 60745.
Typically the A-weighted noise levels of the product are:
Sound pressure level 85 dB(A); Sound power level 96 dB(A).
Uncertainty K =3 dB.
Wear hearing protection!
Vibration total values a (triax vector sum) and uncertainty K
h
determined according to EN 60745:
Hammer drilling into concrete: a =13 m/s
h
2
Drilling into metal: a =4 m/s , K=1.5 m/s
h
2
Screwdriving: a <2.5 m/s , K=1.5 m/s
h
2 2
, K=3 m/s ,
2
,
2
.
