EN
1- Air flushing
Meter must be completely flushed to work correctly (cf.
LCD after correct flushing (cf.
LCD after incorrect flushing. Air in pipe icon displayed. (cf.
2- Radio activation (cf.
» Automatically after 1 mins with meter in water
» or via NFC Field Tool
Scan this 2D bar code to download
NFC fieldtool application & user guide
» Radio Activated when Periodic SHIP message is no more displayed
3- Environmental Protection
Environmental Temperature
Restriction for High Temperature on
Yearly Basis
Storage Temperature
Transport
Electromagnetic Class
IP68
4- LCD overview
4.1 General LCD overview (cf.
The lid must be closed to better protect LCD display against direct sunlight.
4.2 Display overview
Icons
1
2
3
4
5
6
7
8
m
/h
3
* Configurable by NFC
2
)
4
)
-25°C to 70°C
3 months with max 55°C for 18 hours/day & max 70°C for 6 hours/day
9 months with max 30°C for 18 hours/day & max 50°C for 6 hours/day
5°C to 35°C
Min -25°C (< 72 hours continuous)
Max +70°C (< 72 hours continuous)
E2
X8 = Under 2 m of water at 50°C during 2 months
5
)
Information
Main display 8/9 digits
Battery level indicator
System or application
Alarm indicator
Leakage indicator
Air in pipe indicator
Freezing alarm
Test mode indicator
Flowrate indicator
1
)
3
)
area
12 Months battery remaining (before the
expected end of life date of the battery) or
battery voltage level alarm
General icon in case of unspecified critical alarm
Leakage of previous day*
Air in pipe for more than 10 seconds
If temperature falls < 2°C during the previous day*
Product in Test Mode*
Current flowrate, backflow if minus sign is displayed
