3.9 OPERATING PRINCIPLE OF THE
VALVE
GAV 2.0 XABO
Horizontal body position
Fig. 2: GAV 2.0 in the horizontal position
a) closed b) open
Vertical body position
GAV 2.0 XABO
GAV 2.0 XABO
Fig. 3: GAV 2.0 in the vertical position
a) closed b) open
NOTE
During physical activity associated with shock
(e.g. jogging), the opening pressure of the GAV
2.0 XABO may decrease temporarily according to
laboratory results. Fundamentally, though, func-
tionality remains the same. At the end of physical
activity, the opening pressure returns to its origi-
nal level and remains stable.
3.10 SELECTION OF THE APPROPRIATE
PRESSURE SETTING
2.0 XABO
Horizontal body position
