EN
No. Component
4 Battery state of charge
5 Voltage and current display

7 Installation

The electrical power supply must be connected by a qualified electrician who has demonstrated skill and
knowledge related to the construction and operation of electrical equipment and installations, and who
is familiar with the applicable regulations of the country in which the equipment is to be installed and/or
used, and has received safety training to identify and avoid the hazards involved.

Installation location

When selecting an installation location, consider the following:
• The mounting surface must be even and sufficiently solid.
• The battery monitor must be installed in a location that is protected from moisture and dust.
• Install the battery monitor inside the vehicle.
• Install the battery monitor in a well ventilated area, away from flooded batteries and places with free acid
gasses.
Mounting the display panel
NOTICE! Damage hazard
• Using wrong cables can lead to excessive overheating of the cables, high voltage drops, and possi-
ble failures. Use only the cable supplied.
• Ensure that no electrical cables or other parts of the vehicle can be damaged by before drilling any
holes.
10
Description
Shows the battery state of charge in % and in a ring diagram.
• Red part: Displays the charge drawn from the battery.
• Green part: Displays the current state of charge.
Shows the battery voltage and the battery current.
