Error codes on the hand control display
Error Code List - ControlForce 2 (CF2)
Error Code
E01 ERR_LIMIT_UP
E02 ERR_LIMIT_DOWN
E03 ERR_SYSTEM_ERROR
E04 ERR_OVERCURRENT
E05 ERR_OVERCURRENT_MOTOR1
E06 ERR_OVERCURRENT_MOTOR2
E07 ERR_OVERHEAT
E08 ERR_MISSING_MOTOR1
E09 ERR_MISSING_MOTOR2
E10 ERR_RESET_TRIGGERED
E11 ERR_ACTISENSE_TRIGGERED
Name Error Condition
System trigger E01 when
trying to move frame up
System trigger E02 when
trying to move frame down
- Erase flash sector failed
- Write flash data failed
- ADC offset exceeded limit
System detected motors
have exceeded the total
current limit
System detected Motor 1 to
be loaded at more than
preset motor current ( 6A )
System detected Motor 2 to
be loaded at more than
preset motor current ( 6A )
Total System Work (Joule)
hits the preset Heat monitor
Threshold
System unable to detect
the present of Motor Chan-
nel 1
System unable to detect
the present of Motor Chan-
nel 2
System undergo the Reset
Process
System detected high rota-
tional movement through
Gyro Sensor
Description
Reached software up- Move frame downwards
per limit instead of upwards
Reached software low- Move frame upwards
er limit instead of downwards
System failed to erase/
Replace the control box
write data to flash or
failed ADC offset self-
test.
System has exceeded Remove some loads
the total current limit for from the table top
all motors combined
Over current / Short Remove some loads or
Circuit on Ch1 Motor distribute the load more
evenly on table top
Over current / Short Remove some loads or
Circuit on Ch2 Motor distribute the load more
evenly on table top
System incorporate Rest the table top for 10
software protection mins to resume full desk
against motor overheat-
capability.
ing
Motor 1 not detected Check whether the Mo-
tor Cable plug for M1
was properly plugged in
Motor 2 not detected Check whether the Mo-
tor Cable plug for M2
was properly plugged in
Reset Process Press the "DOWN" button
to move the desk to the
lowest position to com-
plete the RESET process
Collision detected Check if the desk hits
any obstacles along the
desk's movement path
or getting held by any
hanging wires
English
Solution
