actiforce ControlForce 2 Montageanleitung Seite 10

Error Code Name
ERR_OPERATIONMODE_CHAN
E12
GED
ERR_CASCADING_CONFIG_MI
E13
SMATCH
E14 ERR_CONFIG_FORCE_RESET
E15 ERR_RESET_REQUIRED
E16 ERR_SLEEP
E17 ERR_MOTOR_SYNC
E18 ERR_CASCADING_SYNC
E99 HandSwitch Reading Error
Error Condition
Changed of standalone or
cascading mode
Configuration mismatch for
both cascading controller
System detected Configu-
ration Change
System detected uncorrect-
able error that require to
perform Desk System reset
System stuck in sleep mode System failed to update
Two driver motor positions
are out of sync
Two tables are out of sync
- Handswitch plugged into
COM port instead of HS port
- Cable connector inside
the switch is loose
Description
Controller operation Reset the table top by
mode changed to long press the "DOWN"
standalone or cascad- button to perform the
ing mode RESET process
Both controllers has dif- Remove the Cascading
ferent configuration connection.
settings
Controller was updated Reset the table top by
with new parameter file long press the "DOWN"
button to perform the
RESET process
Reset is required to cor- Reset the table top by
long press the "DOWN"
rect detected error.
button to perform the
RESET process
Disconnect control box
the low power mode from power source, wait
flag and system might for at least 10 seconds
still be in low power
and power it on again.
mode
Rotational difference of Reset both frames by
1.0 rev or more between long press the "DOWN"
button to perform the
two driver motors
RESET process
Position difference of Reset both table tops by
5mm or more between long press the "DOWN"
two tables button to perform the
RESET process
Handswitch can't read Plug Switch into HS port
data from Controller instead of COM port
English
Solution
10
