Error Code Name
ERR_CASCADING_CONFIG_MI
E13
SMATCH
ERR_CONFIG_FORCE_RESET
E14
E15 ERR_RESET_REQUIRED
E16 ERR_SLEEP
ERR_CASCADING_SYNC
E18
ERR_MOTOR_NUM_MISMATCH
E20
E99 HandSwitch Reading Error
Error Condition
Configuration mismatch for
both cascading controller
System detected Configura-
tion Change
System detected uncorrect-
able error that require to
perform Desk System reset
System stuck in sleep mode System failed to update
Two tables are out of sync
Mismatched in number of
connected motor
- Handswitch plugged into
COM port instead of HS port
- Cable connector inside
the switch is loose
Description
Both controllers has Remove the Cascading
different configuration connection.
settings
Controller was updated Reset the table top by
with new parameter file long press the "DOWN"
button to perform the
RESET process
Reset is required to cor- Reset the table top by
rect detected error. long press the "DOWN"
button to perform the
RESET process
Disconnect control box
the low power mode from power source, wait
flag and system might for at least 10 seconds
still be in low power and power it on again.
mode
Position difference of Reset both table tops
5mm or more between by long press the
"DOWN" button to per-
two tables
form the RESET process
Number of motor de- Check whether both of
tected by system does the Motor Cable plug
not match the settings was properly plugged in
Handswitch can't read Plug Switch into HS port
data from Controller instead of COM port
