actiforce ControlForce 2 Montageanleitung Seite 11

Error Code List - ControlForce 2 Pro (CF2 pro)
Error Code
E01 ERR_OVERLOAD
E03 ERR_SYSTEM_ERROR
E04 ERR_OVERCURRENT
ERR_OVERCURRENT_MOTOR1
E05
ERR_OVERCURRENT_MOTOR2
E06
E07 / Hot ERR_OVERHEAT
E08 ERR_MISSING_MOTOR1
E09 ERR_MISSING_MOTOR2
E10 ERR_RESET_TRIGGERED
ERR_ACTISENSE_TRIGGERED
E11
ERR_OPERATIONMODE_CHAN
E12
GED
Name Error Condition
System operates at Max
System Current which cause
the movement speed to
drop lower than 75% more
than 500ms
- Erase flash sector failed
- Write flash data failed
System detected motors
have exceeded the total
current limit
System detected Motor 1 to
be loaded at more than
preset motor current ( 6A )
System detected Motor 2 to
be loaded at more than
preset motor current ( 6A )
Total System Work (Joule)
hits the preset Heat monitor
Threshold
System unable to detect the
present of Motor Channel 1
System unable to detect the
present of Motor Channel 2
System undergo the Reset
Process
System detected high rota-
tional movement through
Gyro Sensor
Changed of standalone or
cascading mode
Description
System incorporate soft- Remove some loads
ware protection against from the table top
heavy load
System failed to erase/ Replace the control box
write data to flash
System has exceeded Remove some loads
the total current limit for from the table top
all motors combined
Over current / Short Remove some loads or
Circuit on Ch1 Motor distribute the load more
evenly on table top
Over current / Short Remove some loads or
distribute the load more
Circuit on Ch2 Motor
evenly on table top
System incorporate soft- Rest the table top for 10
ware protection against mins to resume full desk
motor overheating capability.
Motor 1 not detected Check whether the
Motor Cable plug for
M1 was properly
plugged in
Check whether the
Motor 2 not detected
Motor Cable plug for
M2 was properly
plugged in
Reset Process Press the "DOWN" but-
ton to move the desk to
the lowest position to
complete the RESET
process
Collision detected Check if the desk hits
any obstacles along the
desk's movement path
or getting held by any
hanging wires
Controller operation Reset the table top by
mode changed to long press the "DOWN"
standalone or cascad- button to perform the
ing mode RESET process
English
Solution
11
