Danfoss RA
The Danfoss valve bodies have elongated notches (1)
around their circumference, which also ensure that the
adapter is properly seated when it snaps on.
During installation, please ensure that the pins
inside the adapter (2) are lined up with the
notches (1) on the valve. Ensure that a suitable
adapter for the valve is properly clipped on.
After clipping onto the valve body, please attach the
adapter using the provided screw and nut.
