4. PARAMETER MENU
The thermostat has a parameter menu. In order to enter this
menu, simultaneously press and hold the "" and "" keys
for 8 seconds until , in section 11 of the LCD display, and
"rF" is displayed on the screen.
Parameters can be selected using the left "" and right ""
navigation buttons. Once the required parameter is
displayed, press the "OK" button. Modify the parameter
settings with the "+" or "-" buttons and confirm your
adjustment with the "OK" button.
To exit the parameter menu, choose the parameter
"END" and press the "OK" button.
DEFAULT VALUE & OTHER POSSIBILITIES
00 rF: WIRELESS RADIO INITIALIZATION (PAIRING)
Press "OK" to enter this initialization sequence.
The digits will cycle showing that the digital thermostat is
waiting for a radio link signal from the gateway to be
received (press "" to cancel radio initialization). When the
radio link signal is received, pairing is saved, then it will
return to the main screen, but now the cloud and antenna
symbols will be displayed.
01 ALL: EXPERT SETTING
Press "OK" to enter this parameter. Select with "+" or
"-" and confirm by pressing the "OK" button:
no: Basic mode (only Program and Comfort modes
available).
YES: Advanced mode (all modes available).
NOTE: If connected to a Unisenza+ Gateway, this setting will
not be available.
02 dEG: TYPE OF DEGREES DISPLAYED
Press "OK" to enter this parameter. Select with "+" or
"-" and confirm by pressing the "OK" button:
°C = Celsius
°F = Fahrenheit
NOTE: If connected to a Unisenza+ Gateway, this setting will
not be available.
03 __._ : CALIBRATION OF THE INTERNAL PROBE
The calibration must be done after 1 day working with the
same setting temperature in accordance with the following
description:
Put a thermometer in the room at 1.5m distance from the
floor (like the thermostat) and check the real temperature
in the room after 1 hour.
When you enter the calibration parameter screen the
actual temperature value is displayed.
To enter the value shown on the thermometer, use the
"-" or "+" buttons to enter the real value. At this point the
hand icon, in section 17 of the LCD display, will be
displayed and the value will blink. Press the "OK" key to
confirm and save. If you need to erase a calibration already
saved use the "-" or "+" buttons to alter the value, even just
by 0.5°C , then press the left "" navigation button. The
hand symbol will disappear and the factory calibrated
temperature reading will be displayed.
NOTE: Only the heating elements (including follower
radiators) managed by the thermostat must be used during
the calibration process. Do not have a secondary heat
source in the same room for a period of 24 hours before
hand.
NOTE: If connected to a Unisenza+ Gateway, this setting
will not be available.
04 SurF: FRONT PANEL TEMPERATURE
LIMITATION
This power setting can be used to limit the output of the
heating element in the front panel and as a consequence
will limit the surface temperature of the front panel.
Press "OK" to enter this parameter. Select with "+" or
"-" and confirm by pressing the "OK" button:
no = 100% (default).
Mid = 70%
Lo = 55%
NOTE: If connected to a Unisenza+ Gateway, this setting will
not be available.
