3A
SINGLE PANEL YALI DIGITAL RADIATOR
H A B
(mm) (mm) (mm)
300 100-150 37
500 100-150 37
3B
SINGLE PANEL YALI PARADA/RAMO
RADIATOR
H A B
(mm) (mm) (mm)
300
100-150 150-200
500
100-150 150-200
3C
DOUBLE PANEL RADIATOR
H A B
(mm) (mm) (mm)
300
100-150 46
500 100-150 46
C
(mm)
173
373
C D
(mm) (mm)
89 173
89 373
C
(mm)
173
373
A
A
A
