8. Draw the two drill holes for the retaining
plate (6) on the wall.
9. Remove the flue screen (2) from the
exhaust hood again.
10. Drill dowel holes in the wall at the marked
areas.
11. Place the flue screen on the exhaust
hood again.
12. Screw the retaining plate (6) tightly onto
the wall with two screws.
(6)
(2)
(1)
13. Only for exhaust air operation: Insert the
14. Guide the mains cord covered in the flue
(6)
15. Pull up the upper part of the flue screen
16. Remove the blue protective film from the
Assembly
end of the exhaust hose (3) with the lar-
ger diameter (153 mm) into the connecti-
on with the check valve.
screen to a properly installed socket and
insert the mains plug into the socket.
(5)
to the upper wall mount (5) and screw on
the flue screen tightly with two screws (8).
parts of the flue screen.
Page EN-15
