3 Product description

3.1 Construction
1
5a
5b
6
7
8
9
11
12
13a
14
Item Name
1 Optical position indic-
ator
2 Manual override
3 Actuator top with LED
display
4 Actuator base
5a Electrical connection
X2
(only for positioner
design)
5b Electrical connection
X1
6 Distance piece
7 Union nut
8 Distance piece with
mounting flange includ-
ing EPDM seal
9 Compressor
10a Valve body
10b Valve body
11 Locking ring
12 Tube holder
13a Tube carrier
13b Tube carrier
14 CONEXO RFID chip
www.gemu-group.com
2
3
4
10a
11
12
13b
14
Materials
PA 12
Polyamide, 50% glass
fibre
Polyamide, 50% glass
fibre
Stainless steel
Stainless steel
Stainless steel
Stainless steel
PA6
Stainless steel/PA6
PA6
PA6
PA6
Stainless steel

3.2 LED displays

3.2.1 Status LEDs
LED
Standard
Power/fault
10b
Open
Error
Closed
1) Inversed representation of the OPEN and CLOSED LEDs, ad-
justable via IO-Link
3.2.2 LED conditions
Status Power/
process fault
valve
OPEN posi-
tion
CLOSED po-
sition
Position un-
known
Initialization
lit (on)
3.3 Description
The GEMÜ Q50 eSyStep 2/2-way pinch valve is motorized.
The eSyStep actuator is designed as an actuator with integ-
rated positioner. The valve guides a tube which is com-
pressed from above by a compressor to control and regulate
media. The compressor's specially developed contour and the
tube holder's contour minimize the strain on the tube and thus
increase the tubes' service life. Tubes can be safely inserted
and removed in simple steps and without tools. An optical
and electrical position indicator is integrated as standard.
61 / 112
3 Product description
Colour
Inversed 1)
green green
red red
orange green
red red
green orange
Open Error
Open and Closed flash
alternately
LED conditions
flashes
GEMÜ Q50 eSyStep
Function
Operating indica-
tion/
communication
status
Process valve in
OPEN position
Error
Process valve in
CLOSED position
Closed
off
