ASSEMBLY
Installation of aluminium suction tube
Insert the end of the aluminium alloy tube into the suction hole of the vacuum cleaner body horizontally (see
the picture below). Make sure the tube fits snugly in the hole. You can tell if the tube is correctly inserted by
an audible click.
If you want to pull the tube out, press the release button and pull the tube out.
Installation of motorized floor brush
• Insert the motorized brush into the snap connection of the suction
tube (see picture 1). You can tell by an audible click that it is correctly
inserted.
• If you want to pull the brush out, press the release button and pull
the brush out. (see picture 2)
2 in 1 combined nozzle
The combined nozzle is suitable for cleaning small surfaces, crevices
or irregular objects, such as corners, window slits, internal parts of
appliances, drawers, keyboards, etc.
CONTROL
1. Preparation
Make sure the battery is sufficiently charged before use. We recommend
charging the battery for at least 6 hours before first use.
2. Start
Start the vacuum cleaner by pressing the main switch. Press again to turn off the vacuum cleaner.
3. Switching operating modes
The default mode of the vacuum cleaner is low speed mode, press the C6 button once to switch to high speed
mode. Press again to return to low speed mode.
4. Empty the dust container and clean the filter
We recommend emptying the dust container after each use. The filter set inside is washable and recyclable.
Just wash the filter set under running water and put it back on after it has dried perfectly.
