6. Product details

This model is an all-wheel-drive RC car with a built-in Brushed Electric Motor and a 2.4 GHz receiver, a
programmable electronic driving controller and a steering servo.
The RC model is pre-assembled ready to drive and comes with a remote control transmitter.
The model is designed for both indoor and outdoor operation.
The chassis is lightweight and torsion-resistant. The encapsulation protects the transmission from dirt
and stones. The electronic speed controller is optimally tuned to the engine and impresses with its
excellent starting behavior as well as acceleration and synchronization properties.
The powerful steering servo has a high actuating torque and high actuating speed with maximum
stability. A servo saver protects the servo in the event of violent impacts against the wheels.
With the 2.4 GHz remote control system, you have a system that is primarily ideal for model cars. Two
control functions can be operated remotely via the proportional function channels.
The 2.4 GHz transmitter and the receiver tuned to it do not operate on a frequency fixed by transmitter
and receiver quartz. After each switch-on, the transmitter and receiver scan the frequency band for an
available, free frequency on which the radio connection is then established.
Intended use
The product is designed exclusively for private use. Improper use may endanger persons and cause
damage to the product and associated risks, e.g. loss of control, short circuit, fire, etc.
Observe the safety instructions in these operating instructions. These contain important information
on handling the product. The product is suitable for children under 14 years of age only under adult
supervision.
Dispose of the model, battery and charger in accordance with the legal regulations.
Avoid longer full-throttle runs and let the motor, controller and batteries cool down sufficiently bet-
ween each run!
USB charger:
1. Connect the USB charging cable to a USB port with at least 1.5 A.
e.g.: Computer, USB power supply, power bank, etc.
2. Now connect the battery to the USB charging cable.
3. A red LED in the USB connector starts to light up - this indicates the charging process.
4. As soon as the battery is fully charged, this red LED will turn off.
5. Disconnect the battery from the charging cable and the charging cable from the power source.
Technical data - MODSTER Desert Rookie, brushed:
Scale:
Length/width/height:
Weight:
Ground clearance:
Track front/rear:
Wheelbase:
www.modster.at
1:18
280mm / 185mm / 115mm
625g
20mm
185mm
160mm
