(28)
(23)
5. Turn the lower hinge (23) over and screw
the hinge pin (28) and snap ring (29) back
on.
(4)
6. Unscrew the left screw foot (4).
Fitting the lower hinge and
appliance door
(23)
(22)
(4)
1. Screw on the lower hinge (23) on the left
with the two screws (22) and screw the
screw foot (4) back in.
2. Place the appliance upright.
3. Re-insert the appliance door (2).
Assemble the upper hinge
(29) (17)
(27)
1. Tighten the upper hinge (18) with the
screws (20).
2. Re-place the hinge cover (17).
3. Re-place the cover (19) on the opposite
side.
4. Insert the blind plug (21).
First use Page EN-25
(20)
(18)
(19)
(21)
