ENGLISH
WARNING: To reduce the risk of
serious personal injury, ALWAYS hold
securely in anticipation of a sudden
reaction.
DCF680
Proper hand position requires one hand on the main
handle as shown in figure 5a.
WARNING: If the tool will be used
in elongate position and highest MR
please hold tool with both hands as
shown in figure 5b.
DCF682
Proper hand position requires two hand on the tool
as shown in figure 5c.
Screwdriving (fi g. 1, 5)
Your screwdriver uses gyroscopic technology to
sense your hand motion. To operate, press in the
motion control activation trigger and turn your hand
in the direction that you want the screwdriver to
operate.
SETTING INITIAL STARTING POINT
1. Grasp the screwdriver as shown in figure 5.
2. Press and hold in the motion control activation
trigger.
3. When the LED illuminates the tool is ready for
use.
4. To reset initial starting point first release the
motion control activation trigger. Move tool to
new position, then press and hold in the motion
control activation trigger.
OPERATING IN FORWARD DIRECTION
1. Grasp the screwdriver as shown in figure 5.
2. Engage head of fastener with screwdriver
accessory on work piece. Follow instructions for
setting initial starting point.
3. Rotate your hand clockwise and the screwdriver
will activate in the forward direction.
OPERATING IN REVERSE DIRECTION
1. Grasp the screwdriver as shown in figure 5.
2. Engage head of fastener with screwdriver
accessory on work piece. Follow instructions for
setting initial starting point.
3. Rotate your hand anti-clockwise and the
screwdriver will activate in the reverse direction.
To turn the tool off, release the motion control
activation trigger.
36
NOTE: When the tool is not in use or during transit
please be sure to remove any accessory from the
tool and activate trigger lock (b).
VARIABLE SPEED
• The spindle speed is dependent upon the
speed that you rotate your hand.
• The slower you rotate your hand, the slower the
screwdriver turns.
• The faster you rotate your hand, the faster the
screwdriver turns.
• If you wish to increase the spindle speed, rotate
your hand further in the same direction.
• If you wish to decrease the spindle speed,
rotate your hand back towards the initial starting
point.

MAINTENANCE

Your D WALT power tool has been designed to
E
operate over a long period of time with a minimum
of maintenance. Continuous satisfactory operation
depends upon proper tool care and regular cleaning.
WARNING: To reduce the risk of
serious personal injury, turn tool
off and disconnect battery pack
before making any adjustments or
removing/installing attachments or
accessories. An accidental start-up
can cause injury.
The charger and battery pack are not serviceable.
Lubrication
Your power tool requires no additional lubrication.
Cleaning
WARNING: Blow dirt and dust out of
the main housing with dry air as often as
dirt is seen collecting in and around the
air vents. Wear approved eye protection
and approved dust mask when
performing this procedure.
WARNING: Never use solvents or
other harsh chemicals for cleaning the
non-metallic parts of the tool. These
chemicals may weaken the materials
used in these parts. Use a cloth
