Model assembly
Vertical stabilizer installation
1.Connect the rudder servo to the preinstalled servo
lead within the fuselage.
2. Install the vertical stabilizer into the fuselage
pocket.
3.Attach the vertical stabilizer to the fuselage using
the included screws.
Canard installation
1.Install the canard halves into the fuselage as
shown.
5
HKM3.0*20mm
