4.3 INSTALLING THE L1 TRIGGER LEVER
1. Attach the adapter to the L2 Lever and screw in
the fixing screw with a 2.5 mm hex key.
2. Tighten the fixing screw with a torque of
max. 2.5 Nm.
3. Attach the L1 Trigger Lever to the adapter.
4. Screw the fixing screw into one of the two
threads using a Torx T25 key.
5. Tighten the fixing screw with a torque of
max. 1.5 Nm.
The position of the remote lever can be adjusted if
necessary.
6. Loosen the screw (1) with a 3 mm hex key.
7. Turn the remote lever to the desired position.
8. Tighten the screw (1) with a torque of 2 Nm.
