- Fasten the angle at lower units under the topsoil, at high units if necessary above the topsoil, drill through the backpanel. - Dowel the aligned and positioned units tightly to the wall (Depending on the wall on site, use the appropriate mounting material!).
Site Montage / Assembly Zu 1.3. Montage Kippsicherung/ To 1.3. Assembly anti-tipping mechanism Winkel mit dem Konstruktionsboden und mit der Wand ver- schrauben. Dübeltechnik an den Untergrund anpassen. Screw the mounting angles to the panel and to the structural wall.
Seite 4
Site Montage Schiebetürenschrank/Assembly sidebord with sliding doors Montage Schiebetürenschrank Assembly sidebord with sliding doors Verschrauben in Konstruktionsboden/ Screw to structural panel Mit der Wand ver- schrauben. Dübel- technik an den Unter- grund anpassen. Screw to the wall. 2 x hinten links / Adapt the dowel tech- rechts Stellfuß...
Seite 5
Measure the position of the mounting plate at furniture and draw the desired height on the wall. The mounting plate must be fastened over a large surface area on the wall.. - By relocating of drillings you can also fasten beside on site installations. In addition, drill if necessary further holes.
Sie darauf, dass der Einhängebeschlag in die Öffnungen eingreift. Messen Sie die passende Montagehöhe an der Schiene ab (Oberkante Schiene = blauer Pfeil) Assembly wall mounted shelf (SITE E74 / E75) Preparation: Insert the white painted mounting rail into the recess on the back of the shelf. Make sure that the suspension fitting engages in the openings.
Seite 7
Site Montage wandhängendes Regal / Assembly wall mounted shelf Einhängen und Ausrichten: Hängen Sie das Regal mit allen 3 Haken (grüner Pfeil) am Montagerohr ein. Oben / innen an den Regalseiten finden Sie je 2 Bohrungen. Mit dem beiliegenden Schraubendreher müssen Sie: 1.) zuerst durch die obere Bohrung die Höhe verstellen (18mm).
Seite 8
