Product overview

1x
1 Function dial
2 Chuck ring
3 Chuck
4 Auxiliary handle
5 Supply cord
6
On / off switch
7 Speed dial
8 Lock on button
9 Rotation direction switch
1x

Intended use

The tool is intended for impact drilling in con-
crete, brick and stone as well as drilling in
metal and wood. The tool is not intended for
commercial use.
Any other use or modification to the tool is
considered as improper use and could cause
considerable dangers.
DE Lieferumfang
FR Etendue de livraison
IT Materiale compreso nella fornitura

Adjustments

NL Leveringsomvang
SV APPLY HANDLE Leveransomfång
1 Widen the auxiliary handle 4 by turning
CZ it and slide it onto the rotary hammer. Rozsah dodávky
SK Caution! Make sure the tool is Rozsah dodávky
switched off and unplugged.
RO Volumul livrat
GB Scope of delivery

Using the tool

1x
1. To switch on the tool, press and hold the on
/ off switch 6. To lock the on / off switch in
position, press the lock on button 8 while
the on / off switch is pressed.
2. Make sure your workpiece can not slip.
Start working, while holding the tool firmly
with both hands.
3. To switch off the tool, press and release the
on / off switch 6.
1x
2 Set the desired angle and tighten the
auxiliary handle 4 by turning it.
EN 121
