1
2
3
1
2. 2.
1. 1.
1
2. 2.
1. 1.
106 EN
9
8
7
6
5
4
2
2

Product overview

1x
1 Locking sleeve
2 Chuck
3 Auxiliary handle
4 Power cord
5 Rear handle
6
Rear hammer-drill/ drill switch
7 Top hammer-drill/ hammer switch
8 On/ off switch
9 Grease box cover
1x

Using the tool

1. To switch on the tool, press and hold the
on / off switch 8.
2. Make sure your workpiece can not slip. 1x
Start working, while holding the tool firm-
ly with both hands.
3. To switch off the tool, release the on / off
switch 8.
APPLY HANDLE
1 Release the noose of the auxiliary han-
DE dle 3 Lieferumfang and slide it onto the rotary ham-
mer.
FR Etendue de livraison
IT Caution! Make sure the tool is Materiale compreso nella fornitura
switched off and unplugged.
NL Leveringsomvang
SV FIT CHISEL OR DRILL Leveransomfång
1 Slide back the locking sleeve 1. Fit
CZ the SDS-plus chisel or drill into the Rozsah dodávky
chuck 2.
SK Rozsah dodávky
Caution! Make sure the tool is
RO switched off and unplugged and Volumul livrat
wear protective gloves.
GB Scope of delivery

Intended use

1x
The tool is intended for hammer drilling in con-
crete, brick and stone. It can be set to rotation
only for drilling in metal and wood and also for
hammer function only for chiseling brick, con-
crete and masonry products. The tool is not
intended for commercial use.
Any other use or modification to the tool is
considered as improper use and could cause
considerable dangers.
1x
1x
2 Set the desired angle and tighten the
auxiliary handle 3 securely.
2 Make sure that the chisel or drill is
fully inserted.
Release the locking sleeve 1 and check
if the chisel or drill is securely fixed.
To remove the chisel or drill, slide back
the locking sleeve 1 and pull out the
chisel or drill.
EN 107
