FIT CHISEL OR DRILL
1
Slide back the chuck ring 2. Fit the
SDS-plus chisel or drill into the chuck 3.
Caution! Make sure the tool is
switched off and unplugged and
wear protective gloves.
HAMMERING WITH POINT CHISEL
1
Push the button on the function
and set the function dial to hammering
without fixation
or with fixation .
Caution! Only set operation modes
while the chuck ring is standing still.
HAMMER-DRILLING
1
Push the button on the function
and set the function dial to hammer-
drill
.
Caution! Only set operation modes
while the chuck ring is standing still.
DRILLING
1
Push the button on the function
and set the function dial to drill .
Caution! Only set operation modes
while the chuck ring is standing still.
INCREASING SPEED
1
The deeper the on / off switch
pressed, the faster the rotation.
Turn the speed
dial 7
clockwise to in-
crease the max. speed.
122
EN
2
Relase the chuck
ring 2
and ensure that
the chisel or drill is securely fixed.
(To remove the chisel or drill, slide back
the chuck
ring 2
again and pull out the
chisel or drill.)
HAMMERING WITH FLAT CHISEL
dial 1
2
Push the button on the function
and set the function dial to hammering
with fixation .
Caution! Only set operation modes
while the chuck ring is standing still.
dial 1
2
For hammer-drilling push in the rota-
tion direction
switch 9
on the side with
the arrow pointing forward.
dial 1
2
For drilling push in the rotation direc-
tion
switch 9
on the side with the arrow
pointing forward.
Push in the rotation direction switch on
the side with the arrow pointing back-
wards to release jammed drills.
REDUCING SPEED
6
is
2
Release the on / off
switch 6
reduce speed.
Turn the speed
dial 7
counterclockwise
to reduce the max. speed.
1
2. 2.
dial 1
1
1
1
slightly to
1
1.
1.
2
2
2
2
2
EN
123
