Optional Accessories; Hard Water Kit (Apwm062); Apwm 019/020 Connector Box - Miele PWM 920 EL/RH Installationsplan

Hard water kit
(APWM062)
APWM 019/020
Connector Box
Peak load / energy
management
Make sure that you only drill through the first panel (I) as there is a
deflecting panel (II) 10 mm behind it.
Connections 3 to 12 are provided for liquid detergent. High-pressure
dispensing systems with water injection must not be connected to
these connections. The connectors are sealed and must be cut to the
diameter of the hose with a small saw before they are connected.
If opened connectors are no longer required, they must be resealed
using a suitable sealant (e.g. silicone).
External dispensing pumps are connected and calibrated via the
Connector Box, which is available as an option.
A flowmeter or flow sensors can also be connected for monitoring the
dispensing quantity precisely.
Connections for level monitoring are available for every agent dis-
pensed.

Optional accessories

Only use genuine Miele spare parts and accessories with this ma-
chine.
Using spare parts or accessories from other manufacturers will in-
validate the guarantee, and Miele cannot accept liability.
The hard water connection on the washing machine can be retrofitted
with the optional hard water kit (APWM062).
The additional water connection allows hard water to be used and
the programme running time will therefore be reduced. In addition,
hard water is particularly suitable for the final rinse cycles.
The Connector Box allows external hardware from Miele and other
suppliers to be connected to the Miele Professional washing ma-
chine.
Flowmeters for the water inlet can also be connected to the Con-
nector Box (APWM 065).
A peak-load or energy management system can be connected via the
Connector Box.
en - Installation notes
31
