CONNECTION OPTIONS

Connect the soundbar to your TV using one of the following connection options:
• Option 1 (preferred): HDMI eARC (Enhanced Audio Return Channel) or ARC
• Option 2: Optical
NOTES:
• To deliver the Dolby Atmos surround-sound experience, connect the soundbar to
the HDMI eARC or ARC port on your TV (see page 55). If your TV doesn't have
an eARC or ARC port, you can connect the optical cable to the optical port to
receive spacious and life-like sound (see page 56).
• To use your TV remote to control the power, volume, and mute functions of the
soundbar, the soundbar must be connected to the HDMI eARC or ARC port on
your TV.
1. On the back of your TV, locate the HDMI IN and Audio OUT (optical) ports.
NOTE: Your TV port panel may not appear as shown. Look for the shape of
the port.
HDMI IN Audio OUT Audio IN
HDMI ARC Optical Optical
HDMI ARC
2. Choose an audio cable.
AP P EN D I x : SET UP R E F E RE NC E
Option 1 (Preferred)
HDMI eARC (or ARC): Use the
HDMI cable for this connection.
Option 2
Optical: If your TV doesn't have an
HDMI eARC (or ARC) port, use the
optical cable for this connection.
|
5 4 E N G
