DIRECT MEASUREMENT
• Fit the ACS to top hat rail. To do so, hook the device on the
upper edge of the top-hat rail and press down until it clicks
into place.
• Connect ACS as per the diagrams below
• Check the setting on the DIP switches S1, S2, S3 and the DIP
switch S4 (see diagram of AC Sensor layout for position of
switches).
S1
• Close/secure the housing cover with one of the enclosed cable
ties
28
S2 S3 S4
