Operating Instructions smartBOX
Start of Line Dispense
You have to specify the following parameters:
Line Dispense Setting Unit Choose whether you want to specify the speed/quantity by
Setting Unit
When you specify a volume or weight as well as a flowrate, the movement speed of the
robot axis will be set automatically so that it matches the specified amount .
The master stetting for the KEEP / CHANGE funktion is always the initial data at "Start of
Line Dispense"
Line Passing
Change of direction during a Line Dispensing . Please also refer to the picture above . You
have the following options:
Dispense Output
The following two options are only necessary if you specified an axis speed ([mm/s]) on
the Start of Line Dispense . Please also see the picture below for explanation .
Line Speed
Keep / Change
axis speed (mm/s), volume (µl, ml) or weight (mg, g)
-> Enter the numeric value of the speed/quantity chosen
before .
Choose whether you want to specify the flowrate by
percentage of the max . flowrate (%) or absolute (ml/min)
-> Enter the numeric value of the flowrate chosen before .
Choose whether you want to continue (ON) or stop the
dispensing (OFF) when passing the set point .
When Dispense OFF is selected you can choose if the suck
back will be executed or not . You can do this with the
funktion Suck Back ON/OFF
Specify the axis speed in [mm/s] to which the axis should
change when passing the set point
Keep: Choose this option if you want the line width to be
constant (the flowrate will be increased/decreased
automatically based on change in axis speed)
47
VIEWEG
EN
