VIEWEG
Wait Time at Start
Wait Time at Stop
EN
Return Type
excess
accurate
eco-PEN Models
Flow Rate Conv. Coef.
Default values to reset calibration:
Flow Rate Adj. Value
Dispensing time executed before the robot starts to move .
This option might be useful to get your material flowing
evenly, especially for material with high viscosity .
Wait time after the robot movement in order to stop the
material flow and allow to equalize the outlet pressure to
prevent unwanted material deposition .
Retract movement of the robot after reaching the end of
a dispense line . This is a feasible option to lay down
dispense line ends .
- Z up only: A retract movement in the z-axis only
- XY moving after Z up: A retract movement in the z-axis
followed by a retract movement in the XY axis
- XYZ simultaneous: Retract movement of all three axis
Specify the desired distances and speed for the retract
movement as well as the desired wait time after the retract
movement via:
Z return Height,
XY return dist . ,
Return line speed and
Wait time after return .
Select the eco-PEN you are using in this program .
It is recommended to execute auto recognition .
Conversion coefficient for flowrate calibration . This value is
specific to the eco-PEN model and must not be changed
by the user unless within the calibration routine .
eco-PEN300: 0,0148
eco-PEN330: 0,033
eco-PEN450: 0,06
eco-PEN600: 0,16
eco-PEN700: 0,6
Adjustment Value used to compensate for changes in the
flowrate caused by a change of the dispensing material or
wear of the eco-PEN .
(Manual calibration 90 - 110%)
Operating Instructions smartBOX
material in a controlled way in order to get
42
NOTICE
