Vibrating Steam Mop
LIST OF CONTENTS
Items Supplied
At A Glance
12
Symbols
Signal Words
Intended Use
Safety Notices
15
Assembly

ITEMS SUPPLIED

• Main unit 1 x
• Handle pole 1 x
• Frame 1 x
• Water tank 1 x
• Cleaning foot 1 x
• Floor cloth 1 x
• Microfibre cloth 1 x
• Carpet glider 1 x
• Window attachment 1 x
• Brush attachment 1 x
• Adapter 1 x
• Operating instructions 1 x
Check the items supplied for completeness
and the components for transport damage.
If you find any damage, do not use the
device but contact our customer service
department.
Remove any possible films, stickers or
transport protection from the device.
Never remove the rating plate and any
possible warnings!
01589_Inlay_DE-EN-FR-NL_A5.indb 11 01589_Inlay_DE-EN-FR-NL_A5.indb 11
11
11
12
13
13
IMPORTANT NOTICES!
PLEASE KEEP FOR REFERENCE!
16
Functions
Filling the Water Tank
17
Use
Cleaning and Storage
19
Troubleshooting
20
Disposal
20
Technical Data

AT A GLANCE

(Picture A1)
1 Handle
2 Hook for winding up the cable
(rotatable)
3 Handle pole
4 Articulated joint
5 Main unit
6 Frame
7 Release buttons for water tank
8 Control lamps (in the main unit behind
the water tank)
9 Vibration on / off switch
10 Carpet glider
11 Cleaning foot
12 Joint + mount for the cleaning foot /
adapter
13 Steam quantity control
14 Water tank
15 Water tank cap
16 On / Off switch with operating lamp
17 Release button for main unit
(Picture A2)
18 Adapter
19 Brush attachment
20 Window attachment
21 Microfibre cloth
22 Floor cloth
EN
17
19
11
