1 I n t r o d u c t i o n
This manual describes the installation process for the tubra
well as its operating and maintenance procedures.
Read this manual carefully before starting any installation work.
Non-compliance will invalidate all claims under the guarantee and warranty.
This manual is intended for trained specialists with an adequate level of expertise in handling
heating systems, water pipe installations and electrical installations.
The installation and commissioning procedures should only be conducted by qualified, spe-
cialist personnel.
®
The tubra -PGS (-C) XL solar station must only be installed and operated in a dry environ-
ment that is protected from frost.
The unit must be installed vertically with the solar connections facing upwards.
Illustrations are symbolic and may differ from product to product.
Subject to technical changes and errors.
1.1

Intended purpose

The solar stations in the tubra
systems with a suitable medium. Any use of a medium other than that specified in the tech-
nical data is not permitted.
Any improper use or modifications to the assembly, structure or components can prevent
safe operation of the system and result in the exclusion of all claims under the warranty and
guarantee.
1.2

Safety instructions

In addition to country-specific guidelines and local directives, the following technical regula-
tions must also be taken into account:

DIN 1988

DIN 12828

DIN EN 12897

DIN 18380

DIN 18382

DIN EN 12975,

DIN EN 12976,

DIN EN 12977

VDE 0100

BGV
As the system can reach temperatures > 60°C, there is a risk of scalding and burning
through contact with the components.
1.3

Applicable documents

Also observe the installation and operating instructions for the various components used,
such as the control unit and the solar pump.
1.4

Delivery and transport

Check to make sure the product is complete and undamaged immediately after receipt. Any
damage or complaints must be reported immediately.
Code no. 977.25.02.00
Dated 06/2018
®
-PGS (-C) XL series are intended for the operation of solar
Technical rules for drinking water installations
Heating systems in buildings
Water supply
Heating systems and central water heating systems.
Electrical cable and wiring systems in buildings
Thermal solar systems and components
Installation of electrical equipment
Accident prevention regulations of workers' compensation
associations
- 3 -
®
-PGS (-C) XL solar station, as
