Technical data

Electrical data
•
Supply voltage
•
Power consumption
•
Model
•
Overvoltage cat.
Dimensions
•
Weight
• Dimensions
•
Cable length
Typical application parameters (example of Standard exchange module)*
Range of applications
•
Plasma temperature*
•
Distance for treatment*
•
Width for treatment*
•
Speed*
Operating conditions
•
Air humidity
•
Temperature
•
Degree of contamination 2
Storage conditions
•
Air humidity
•
Temperature
Gas connection
•
Gas types
•
Gas flow rate / gas inlet
pressure
•
Quality
•
Connection
*
These values are only a course guideline. Depending on treated material, process parameters,
following processes and process requirements the actual results can vary significantly from the
typical parameters in both directions (see chapter 6). Due to the low plasma temperature of
lower than 50 °C a slower treatment is not considered critically.
4

Transport/Storage

•
Store the device in a dry place. This will prevent the electrical contacts from corroding.
•
Protect the device from dirt and foreign objects.
•
Protect the device from falls or other hard impacts.
BA-PZ3_i_ML / F0354901
24 V DC
max. 18 W
Integration unit with gas connection
Category I (DIN EN 60664-1 VDE 0110-1
370 g complete device with module, without connection lines
(178 g module carrier / 202 g driver unit)
40 x 150 x 72 mm (WxHxD); without connecting lines / module
0.3 m
Precision cleaning Adhesive bonding
< 50 °C (at 5 mm distance)
Compressed air 5 to 29 mm; nitrogen 5 to 50 mm
1-15 mm/s 10-150 mm/s
< 80% rel. (non-condensing)
10 – 40 °C; 50 – 104 °F
< 80% rel. (non-condensing)
0 – 60 °C; 32 – 140 °F
- Compressed air (purified, free of oil and lubricants)
- Nitrogen (industrial gases free of particles and oil)
- Additional gas types only after approval from relyon plasma.
8 to 20 l/min; max. 2 bar
Compressed air 1.4.1 acc. to ISO 8573.1
Nitrogen 2.8 (N2) acc. to DIN EN ISO 14175:N1
Hose outer diameter Ø 4 mm (quick coupling)
)
Compression
2 – 10 mm
100-1500 mm/s
