Hand Shower Set (Cono040010) - Conti+ CONFRESH CONE0111211150 Betriebs- Und Montageanleitung

61
Showerheads

Hand shower set (CONO040010)

- Steplessly adjustable hand shower holder
- Stainless steel shrouds
Einstellung der Handbrausehalterung:
- fixed (Fig�1)
- released (Fig�2)
The movement resistance of the hand shower holder can be adjusted:
- Adjusting the resistance for movement on the guide rail (Fig� 3)
- Adjusting the resistance of the hand shower holder (Fig� 4)
