36
Technical data
Operating voltage battery
Operating voltage mains
Operating voltage CNX
Operating pressure (cold water)
Water temperature normal operation
Water flow time adjustment range
Water flow time factory setting
Hygienic flush adjustment range
Hygienic flush factory setting
Output fresh water station
(plate heat exchanger)
Hot water preparation normal conditions
Heating supply line (max�)
Temperature drinking water - side of inlet
Temperature drinking water - side of outlet
Pressure loss heat exchanger unit
Electronic protection type
* When integrated into the CONTI+ ServiceAPP, the BLE Converter must be ordered separately (CONO260000)�
For further information on the CONTI+ ServiceAPP and BLE Converter, please refer to the documentation of the
CONTI+ ServiceAPP�
CONTI Sanitärarmaturen GmbH | Hauptstraße 98 | 35435 Wettenberg | Deutschland | Tel. +49 641 98221 0 | Fax +49 641 98221 50 | info@conti.plus
www.conti.plus | Druckfehler und Irrtümer sowie technische und maßliche Änderungen vorbehalten. | Errors and technical changes remain reserved.
Operating pressure
Flow rate
6 V/DC
12 V/DC
30 V/DC
1,5 - 5,0 bar
2,0 - 5,0 bar
max� 70°C
0,15 l/s (flow regulator)
3 - 180 seconds
30 seconds
12, 24 oder 72 h, can be deactivated via setting on piezo
switch, other hygienic flush intervals can be set via
CONTI+ ServiceAPP* or CNX-System
12 h after last water flow trigger, 30 sec water flow time
35 kW
with 65°C heating water supply
80°C
10°C
45°C
0�22 bar
IP68
