MAINTENANCE

Removing and cleaning the guide rails

Use conventional cleaning products to clean the guide rails.
1. Remove the screw using a screwdriver.
2. Remove the guide rails from the holes in the back wall.
Save the guide rail spacers carefully. Return the spacers after cleaning. This prevents
sparks being created during use.

Replacing the oven lamp

The lamp in this household appliance is only suitable for illumination of this
appliance. The lamp is not suitable for household room illumination.
The light bulbs (2x) (halogen G9, 230 V, 25 W) are a consumer items and therefore not
covered by warranty. To replace it, first remove the baking tray, oven rack and guide rails.
Disconnect the appliance from the power supply by removing the plug from the
socket or by switching off the circuit breaker in the fuse box.
Please note: the light bulb can be very hot! To prevent burns, use protection to
remove the light bulb.
1. Remove the four screws from the cover panel. Remove the cover panel and glass.
2. Remove the light bulb and install a new one.
3. Do not remove the seal from the cover panel. The seal should not become lose from the
cover panel. The seal must fit perfectly in the oven wall recess.
