EN
STEP 4
1. Connect the cable upper & lower ( B-4 & D-17 )
2. Assemble the handlebar post ( B ) onto the mainframe ( D) using screw ( D-12), washer ( D-
11)
STEP 5
1. Assembly the handlebar ( C ) onto the handlebar post ( B ) with screw ( B-1), flat washer ( B-
2 ), spring washer ( B-3)
2. Put the cable ( B-4 ) go through the post and connect pulse wire ( C-3). The put the cover (
C-5)
