EN
13. Put the retractable arm (36) in the arm
(33) and put the lock pin (35) in the
hole for the required capacity and the
cotter (13) in the hole in the lock pin.
Fit the chain and hook (37) on the end
of the retractable arm with a screw (11),
washer (10), spring washers (9) and
nut (8). The arm has 4 holes for different
load capacities. Select the required load
capacity before use.
FIG. 14
14. Fit all the plastic end pieces (32), (38), (39).
HOW TO USE
IMPORTANT:
Stop pumping when the piston has been
run out to the red stop mark, otherwise
the product might not work properly.
FIG. 15
•
Check before each lift that all the screw
unions are properly tightened.
•
Never exceed the maximum permitted
load according to the markings on the
arm. The permitted load is given on a
safety sticker on the arm as follows:
250 kg, 500 kg, 750 kg and 1,000 kg.
•
Never use the product on an uneven
surface or where there are ridges or
expansion joints in the floor – this can
cause the swivel wheels to turn, which can
result in a risk of serious personal injury.
For this reason the swivel wheels are not
covered by the warranty. When moving
with a load the load should hang as low
as possible. Make sure that the load does
not swing. Always lower the load carefully.
Do not let it drop.
•
Check the hydraulic cylinder and piston at
regular intervals for leakage and/or
corrosion. Keep them clean and well
lubricated.
24
•
Small amounts of hydraulic fluid can be
forced out at the base of the piston or at
the top seal. This is perfectly normal.
•
When the product is not in use it should
be stored with the arm and hydraulic
cylinder in the lowest position, the
support feet folded and the lock pins
correctly inserted to minimise storage
space.
•
Only use hydraulic fluid of the type
recommended by the manufacturer
(grade ISO68) when refilling or changing
the hydraulic fluid. Never mix different
fluids and never use brake fluid,
transmission fluid, or engine oil.
Be careful when refilling hydraulic fluid,
so that no impurities or foreign objects
come in the hydraulic system – risk of
material damage.
•
Only use fresh, pure hydraulic fluid.
•
Never allow any part of your body to come
under a load when it is lifted up.
•
Follow these instructions for best
functionality and life span. Do not use the
product for any other purpose than the
one it is intended to be used for.
MAINTENANCE
BLEEDING THE HYDRAULIC SYSTEM
AND REFILLING HYDRAULIC FLUID
1.
Lowering valve
2.
Piston
3.
Refill cap for hydraulic fluid
4.
Mount for pump handle
FIG. 16
1.
Open the lowering valve (1) by turning the
handle anticlockwise.
2.
Press down the piston (2) to its bottom
position.
3.
Remove the filler cap (3).
