1.
Open the bleed valve by turning it
anticlockwise with the piston upright
(as it is installed in the product).
2.
Hold the end of the hydraulic piston
and pump several times with the pump
handle until the resistance no longer feels
"spongy".
STEP-BY-STEP
1.
Fit the swivel wheels (18) on the base (14)
with the screws (19), washers (20), spring
washers (6) and nuts (7). Do not fully
tighten the nuts.
FIG. 2
2.
Move the swivel wheels (18), mounted on
the base (14), along the long holes.
FIG. 3
3.
Move the swivel wheels so that the holes
in the wheels are in line with the holes in
the base and screw the swivel wheels (18)
on the base with the screws (19), washers
(20), spring washers (6) and nuts (7).
Tighten all the four nuts.
FIG. 4
4.
Fit the fixed wheels (5) and the bushings
(4) on the base (14) with the screws (3),
washers (20), spring washers (6) and nuts
(7). Tighten all the nuts.
FIG. 5
5.
Fit the fixed wheels (1) and the bushings
(4) on the base (2) with the screws (3),
washers (20), spring washers (6) and nuts
(7). Tighten all the nuts.
FIG. 6
6.
Put the support feet (2) in the base (14)
from the front and align the hole in the
end of the slot in the base to the hole in
the end of each support foot.
FIG. 7
7.
Fit the coupling plates (16), the base (14)
and support feet (2) with the screws (15)
and (17), spring washers (6), washers
(10), spring washers (9) and nuts (8).
Check that all the nuts are tightened.
Lift one side of the base to align the hole
in the frame to the hole in the support
foot (2), put the lock pin (12) in the hole
and the cotter (13) in the hole in the lock
pin.
FIG. 8
8.
Fasten the handle (31) on the column (26)
with 2 screws (17) and spring washers (6).
FIG. 9
9.
Fit the lower end of the column (26) on
the base (14) with the screws (11), washers
(10), spring washers (9) and nuts (8).
Do not tighten the nuts before completing
the next step.
FIG. 10
10. Screw tight the bottom ends of the stays
(25) on the inside of the base (14) with 2
screws (15), washers (10), spring washers
(9) and nuts (8). Screw the top ends of
the stays on the column (26) with 1 screw
(11), washer (10), spring washers (9) and
nut (8). Check that the nuts are correctly
tightened and tighten the nuts from step 9.
FIG. 11
11. Fit the arm (33) on the top of the column
(26) with a screw (27), washer (22) and
nut (29). Adjust the nuts (29) so that the
arm can swing free.
FIG. 12
12. Screw the bottom end of the cylinder unit
(24) on the column (26) with a screw
(21), washer (22), spring washers (28)
and nut (23). Screw the top end of the
cylinder unit on the arm (33) with a screw
(34), washer (22), spring washers (28)
and nut (23).
FIG. 13
