KRAUSE ClimTec Aufbau- Und Verwendungsanleitung Seite 21

Table of Contents
EN
1. Products ........................................................................................................... 21
1.1 Assembly instructions for locking bolts ...................................................... 22
1.2 Assembly instructions for GuardMatic-System ........................................... 22
2. ClimTec 4 m working height .......................................................................... 23
®
2.1 Assembly instructions ............................................................................... 23
3. ClimTec 6 m working height .......................................................................... 28
®
3.1 Assembly instructions ................................................................................ 29
4. Attaching ballast to the ClimTec
4.1 Using ballast weights ................................................................................. 36
4.2. Using outriggers ........................................................................................ 36
4.3 Fitting the outriggers .................................................................................. 36
5. Disassembling the ClimTec
1. Products
Art.-No. 710383 Without castors
Art.-No. 710369 With Ø 125 mm castors
Art.-No. 710338 With Ø 150 mm castors
................................................................... 35
®
........................................................................... 37
®
4 m
Art.-No. 710390 Without castors
Art.-No. 710376 With Ø 125 mm castors
Art.-No. 710345 With Ø 150 mm castors
ClimTec
®
6 m
21
