Technical Data

Swifty 2
Seat depth (with seat minimizer (accessory))
Seat width (with seat minimizer (accessory))
Back height
min. shoulder height (with seat minimizer (accessory))
Lower leg length
Side guide (W x H)
Back angle
Foot angle
Seat angle, fixed
Safe tilting up to a maximum of
Size of footrest (W x D)
Overall dimensions (L x W x H)
Dimensions when folded (L x W x H)
Push bar height
Turning circle
Wheel size (front (swivelling wheels) / rear)
Wheel width (front (swivelling wheels) / rear)
Weight
Max. load capacity of the basket (accessory)
Max. user weight

Material Specifications

Frame: powder-coated aluminium
Padding: Polyester – Trevira CS
The material used for the padding is "flame retardant" and was tested in accordance with DIN EN 1021-1 and DIN EN
1021-2.
The material and components underwent standard testing to determine the extent of their resistance to inflammation
and were assessed as being very unlikely to catch fire.
The 100% Trevira CS material is a high-quality, breathable material and tested positive for biocompatibility. (DIN EN
ISO 10993-5 and 10993-10 Trevira CS, black)
2021-04
Instructions for Use – Swifty 2
340 - 400 mm (245 mm) / 13.4 - 15.7" (9.6")
395 mm (295 mm) / 15.6" (11.6")
700 mm / 27.6"
470 mm / 18.5" (300 mm / 11.8")
210 - 370 mm / 8.3 - 14.6"
250 x 160 mm / 9.8 x 6.3"
90° - 100°
90°
+ 20°
10°
310 x 200 mm / 12.2 x 7.9"
980 x 670 x 1130 mm / 38.6 x 26.4 x 44.5"
790 x 670 x 490 mm / 31.1 x 26.4 x 19.3"
820 - 1240 mm / 32.3 - 48.8"
1260 mm / 49.6"
180 mm / 250 mm / 7.1" / 9.8"
45 mm / 50 mm / 1.8" / 2"
18,6 kg / 41 lbs
3 kg / 6.6 lbs
50 kg / 110.2 lbs
